6581

Recessed trim projector for indoor application, with orientable light projection. Aluminum body with the possibility of painting in different colors.

General Information

Application
Indoor

General led color
Optional

Mounting Type
Ceiling Recessed

IK
IK03

IP
IP20

CRI
GU10 AR111: >80 | COB: 90

UGR
GU10 AR111: <29 | COB: <19

Class
I

Shape
Circular

MacAdam
COB: 2

Measures
Ø 115 x 160

Standards
EN 60598-1:2015
EN 60598-2-2:2012
IEC 60529
EN 50581:2012,
IEC 61000-3-2:2014
EN 61547:2009

Beam Angle
GU10 AR111: 48º | COB: 34º

Directives
2012/19/UE REEE 2014/30/UE 2014/35/EU

Average Life
GU10 AR111: 25000h | COB: 50000h

Light Source
GU10 AR111 | COB

Light projection
Orientable light projection

Electrical Supply
220-240V AC~50/60Hz

Energy Efficiency
GU10 AR111: G | COB: E

Luminous flux Maintenance
COB: L80B20
