1520-100
Recessed luminaire with trim tab for indoor use, with downward light projection. Aluminium outer body. Remote driver.
General Information
Application
Indoor
Indoor
General led color
Optional
Optional
Mounting Type
Ceiling Recessed
Ceiling Recessed
IK
IK06
IK06
IP
IP20
IP20
CRI
90
90
Class
II
II
Shape
Square
Square
Driver
Remote driver included, not integrated in the luminaire
Remote driver included, not integrated in the luminaire
Measures
45x45x42 F40x40
45x45x42 F40x40
Standards
EN 60598-1:2015
EN 60598-2-2:2012
IEC 60529
EN 50581:2012,
IEC 61000-3-2:2014
EN 61547:2009
EN 60598-1:2015
EN 60598-2-2:2012
IEC 60529
EN 50581:2012,
IEC 61000-3-2:2014
EN 61547:2009
Beam Angle
15º | 36º
15º | 36º
Directives
2012/19/UE REEE 2014/30/UE 2014/35/EU
2012/19/UE REEE 2014/30/UE 2014/35/EU
Light Source
LED
LED
Light projection
Downward light projection
Downward light projection
Electrical Supply
220-240V AC~50/60Hz
220-240V AC~50/60Hz
